IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens with opal diffuser, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Complete with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. Luminaire installation blockout and sealable junction box included in supply.

Colours

Stainless Steel

Material

Body	Stainless steel construction
Fasteners	PCS hardware
Gasket	Silicone rubber gasket
Impact Protection	IK10+
Ingress Protection	IP69
Finish	-
Mounting	Luminaire installation blockout and sealable junction box included in supply

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Complete with cable gland and 0.5 m of flexible PVC-free cable

Additional Information

Rated Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Rated Lumen	CRI	Specifications		Photometrics
					Text	PDF
185-7261	symmetric, diffused distribution	LED-6/12W / 700 mA - 3000 K	369.2	80			ULD
185-7262	symmetric, diffused distribution	LED-6/12W / 700 mA - 4000 K	394.7	80			ULD

Showing 1 to 2 of 2 entries.

Accessories

Control

Mounting Accessories

Part-ID	Title	Specifications
		Text	PDF
430-0013	DALI interface

Item	Download
Product Images
Photometrics
Installation Instructions
