AM series

AM-C

Tubular steel, constant section, hot dipped galvanised. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting flange plate. Columns with a diameter of 114 mm or greater are equipped with a service door. <br><br> Spigot dimensions may vary, dependent on type of luminaire used, and must be specified at time of ordering.

Part-ID	D1	B	C	S	H1	A	T1	Weight
270-9022	76	120	150	10	300	12	---	3.00
270-9023	76	120	150	10	2000	12	---	11.50
270-9024	114	200	250	15	2000	22	90 x 400	24.50
270-9025	114	200	250	15	2500	22	90 x 400	28.50
270-9026	114	200	250	15	3000	22	90 x 400	32.50
270-9027	114	200	250	15	3500	22	90 x 400	36.00
270-9028	114	200	250	15	4000	22	90 x 400	40.00
270-9029	140	200	250	15	4000	22	90 x 400	70.50
270-9030	140	200	250	15	4500	22	90 x 400	78.50
270-9031	140	200	250	15	5000	22	90 x 400	86.00
270-9032	140	300	400	15	5500	30	90 x 400	104.50
270-9033	140	300	400	15	6000	30	90 x 400	112.00
