AM series
AM-S h=6.0-10.0m
Tubular steel, stepped, hot dipped galvanised. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting flange plate. Service door.
| Part-ID | D1 | D2 | B | C | S | H1 | A | T1 | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 270-9010 | 140 | 76 | 300 | 400 | 15 | 6000 | 30 | 90 x 400 | 78.00 |
| 270-9011 | 140 | 76 | 300 | 400 | 15 | 7000 | 30 | 90 x 400 | 89.00 |
| 270-9012 | 140 | 76 | 300 | 400 | 20 | 8000 | 30 | 90 x 400 | 96.50 |
| 270-9013 | 140 | 76 | 300 | 400 | 20 | 9000 | 30 | 90 x 400 | 110.50 |
| 270-9014 | 140 | 76 | 300 | 400 | 20 | 10000 | 30 | 90 x 400 | 116.00 |
