AM series
AMF-C
Tubular steel, constant section, hot dipped galvanised. 5CE+Primer superior corrosion protection, including PCS hardware. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting flange plate with die-cast aluminium cover to conceal mounting hardware. Service door.<br><br>
Spigot dimensions may vary, dependent on type of luminaire used, and must be specified at time of ordering. <br><br>
Planted root is available depending on site-specific requirements; to be ordered separately.
| Part-ID | D1 | B | C | H1 | A | T1 | Weight |
|---|---|---|---|---|---|---|---|
| 270-9333 | 114 | 244-293 | 365 | 2500 | 20 | 70 x 400 | 41.00 |
| 270-9334 | 114 | 244-293 | 365 | 3000 | 20 | 70 x 400 | 45.00 |
| 270-9335 | 114 | 244-293 | 365 | 3500 | 20 | 70 x 400 | 50.00 |
| 270-9336 | 114 | 244-293 | 365 | 4000 | 20 | 70 x 400 | 58.00 |
| 270-9337 | 114 | 244-293 | 365 | 4500 | 20 | 70 x 400 | 61.00 |
| 270-9338 | 114 | 244-293 | 365 | 5000 | 20 | 70 x 400 | 66.00 |
| 270-9339 | 114 | 244-293 | 365 | 5500 | 20 | 70 x 400 | 70.00 |
| 270-9283 | 140 | 244-293 | 365 | 2500 | 20 | 90 x 400 | 57.50 |
| 270-9284 | 140 | 244-293 | 365 | 3000 | 20 | 90 x 400 | 65.50 |
| 270-9285 | 140 | 244-293 | 365 | 3500 | 20 | 90 x 400 | 72.50 |
| 270-9286 | 140 | 244-293 | 365 | 4000 | 20 | 90 x 400 | 87.00 |
| 270-9287 | 140 | 244-293 | 365 | 4500 | 20 | 90 x 400 | 94.50 |
| 270-9288 | 140 | 244-293 | 365 | 5000 | 20 | 90 x 400 | 102.00 |
| 270-9289 | 140 | 244-293 | 365 | 5500 | 20 | 90 x 400 | 111.50 |
