AM series
AML-A
Tubular aluminium, stepped. 5CE+Primer superior corrosion protection, including PCS hardware. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting die-cast aluminium base with covers to conceal mounting hardware. Service door.<br><br>
Foundation cage and Planted root are available depending on site-specific requirements; to be ordered separately.
| Part-ID | D1 | D2 | B | C | S | H1 | A | T1 | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 270-9070 | 140 | 90 | 200 | 270 | 100 | 3000 | 24 | 90 x 400 | 25.0 |
| 270-9071 | 140 | 90 | 200 | 270 | 100 | 3500 | 24 | 90 x 400 | 26.5 |
| 270-9072 | 140 | 90 | 200 | 270 | 100 | 4000 | 24 | 90 x 400 | 28.0 |
| 270-9073 | 140 | 90 | 200 | 270 | 100 | 4500 | 24 | 90 x 400 | 29.5 |
| 270-9074 | 140 | 90 | 200 | 270 | 100 | 5000 | 24 | 90 x 400 | 32.0 |
| 270-9075 | 140 | 90 | 200 | 270 | 100 | 5500 | 24 | 90 x 400 | 33.5 |
| 270-9076 | 140 | 90 | 200 | 270 | 100 | 6000 | 24 | 90 x 400 | 35.0 |
| 270-9077 | 140 | 102 | 200 | 270 | 100 | 3000 | 24 | 90 x 400 | 26.0 |
| 270-9078 | 140 | 102 | 200 | 270 | 100 | 3500 | 24 | 90 x 400 | 28.0 |
| 270-9079 | 140 | 102 | 200 | 270 | 100 | 4000 | 24 | 90 x 400 | 29.5 |
| 270-9080 | 140 | 102 | 200 | 270 | 100 | 4500 | 24 | 90 x 400 | 31.0 |
| 270-9081 | 140 | 102 | 200 | 270 | 100 | 5000 | 24 | 90 x 400 | 33.0 |
| 270-9082 | 140 | 102 | 200 | 270 | 100 | 5500 | 24 | 90 x 400 | 34.5 |
| 270-9083 | 140 | 102 | 200 | 270 | 100 | 6000 | 24 | 90 x 400 | 37.5 |
