AM series
AML-C
Tubular aluminium, constant section. 5CE+Primer superior corrosion protection, including PCS hardware. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting die-cast aluminium base with covers to conceal mounting hardware. Service door. <br><br>
Spigot dimensions may vary, dependent on type of luminaire used, and must be specified at time of ordering. <br><br>
Planted root is available depending on site-specific requirements; to be ordered separately.
| Part-ID | D1 | B | C | H1 | A | T1 | Weight |
|---|---|---|---|---|---|---|---|
| 270-9041 | 100 | 177-217 | 295 | 2000 | 18.50 | 75 x 200 | 11.50 |
| 270-9042 | 100 | 177-217 | 295 | 2500 | 18.50 | 75 x 200 | 12.50 |
| 270-9044 | 100 | 177-217 | 295 | 3000 | 18.50 | 75 x 200 | 13.50 |
| 270-9040 | 140 | 244-293 | 365 | 2500 | 18.50 | 90 x 400 | 22.50 |
| 270-9043 | 140 | 244-293 | 365 | 3000 | 18.50 | 90 x 400 | 25.00 |
| 270-9045 | 140 | 244-293 | 365 | 3500 | 18.50 | 90 x 400 | 27.50 |
