AM series
AML-S
Tubular aluminium, stepped. 5CE+Primer superior corrosion protection, including PCS hardware. Powdercoat finish in black RAL 9004, grey aluminium RAL 9007, anthracite grey RAL 7016 or white RAL 9016. Surface mounting die-cast aluminium base with covers to conceal mounting hardware. Service door. <br><br>
Planted root is available depending on site-specific requirements; to be ordered separately.
| Part-ID | D1 | D2 | B | C | H1 | A | T1 | Weight |
|---|---|---|---|---|---|---|---|---|
| 270-9060 | 140 | 76 | 244-293 | 365 | 2500 | 18.50 | 90 x 400 | 23.00 |
| 270-9061 | 140 | 76 | 244-293 | 365 | 3000 | 18.50 | 90 x 400 | 24.50 |
| 270-9062 | 140 | 76 | 244-293 | 365 | 3500 | 18.50 | 90 x 400 | 26.50 |
| 270-9063 | 140 | 76 | 244-293 | 365 | 4000 | 18.50 | 90 x 400 | 28.50 |
| 270-9064 | 140 | 76 | 244-293 | 365 | 4500 | 18.50 | 90 x 400 | 30.00 |
| 270-9065 | 140 | 76 | 244-293 | 365 | 5000 | 18.50 | 90 x 400 | 32.00 |
