AM series
AML-K
Tubular aluminium, tapered. Chrome-free conversion coating with superior powdercoat finish in RAL colour. Specify required spigot dimensions when ordering. Service door with stainless locking screw. Suitable for one cable connecting box. Standard version with planted root and cable entry hole with cable protection.
Please specify RAL colour reference number according to the WE-EF RAL Colour Chart.
Special version with surface mounting cast base, for installation to a concrete foundation or to a separate planted root, is available on request.
| Part-ID | D1 | D2 | E1 | E2 | H1 | H2 | Spigot | T1 | T2 | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| 240-0221 | 76 | 114 | 800 | 500 | 3000 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 10 |
| 240-0226 | 76 | 114 | 800 | 500 | 3500 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 11 |
| 240-0233 | 76 | 114 | 800 | 500 | 4000 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 12 |
| 240-0238 | 76 | 114 | 800 | 500 | 4500 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 13 |
| 240-0242 | 76 | 114 | 900 | 500 | 5000 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 15 |
| 240-0248 | 76 | 120 | 900 | 500 | 6000 | 600 | Ø 76 | 85 x 400 | 50 x 150 | 21 |
