AM series
AM-Z Type 1
Tubular steel, constant section. Hot dipped galvanised inside and out. Chrome-free conversion coating with superior powdercoat finish in RAL colour. Including spigot. Service door with stainless locking screw. Suitable for one cable connecting box.
Please specify RAL colour reference number according to the WE-EF RAL Colour Chart.
Standard version with planted root and cable entry hole with cable protection. Special version with surface mounting flange plate is available on request.
| Part-ID | D2 | E1 | E2 | H1 | H2 | Spigot | T1 | T2 | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 250-0089 | 102 | 600 | 500 | 3000 | 600 | Ø 76 x 80 | 85 x 300 | 50 x 150 | 27 |
| 250-0099 | 102 | 700 | 500 | 3500 | 600 | Ø 76 x 80 | 85 x 300 | 50 x 150 | 31 |
| 250-0091 | 102 | 800 | 500 | 4000 | 600 | Ø 76 x 80 | 85 x 300 | 50 x 150 | 34 |
| 250-0628 | 102 | 800 | 500 | 5000 | 600 | Ø 76 x 80 | 85 x 300 | 50 x 150 | 48 |
| 250-0092 | 102 | 800 | 500 | 4500 | 600 | Ø 76 x 80 | 85 x 300 | 50 x 150 | 38 |
