DAC100 series
DAC110 LED
IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® gasket. Safety glass lens. Two cable entries. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. Other standardised housing lengths, 250 mm and 300 mm available on request. Optional 2200 K version available. To be specified at time of ordering. Version with emergency lighting on request.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Lens | Safety glass lens |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone CCG® Controlled Compression Gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Finish | Powdercoat |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Standard. Optional DALI version available. To be specified at time of ordering. |
| Cable | Two cable entries |
| Power Supply | 220-240V / 50-60 Hz |
