IP66/67, Class III. IK09. Stainless steel construction including PCS hardware. Silicone gasket. Safety glass lens; max. load 2.5 tonnes. Luminaire can be driven over at low speed. Factory-sealed termination chamber complete with cable gland and 1.5 m of flexible PVC free cable. Integral EC electronic converter in thermally separated compartment. 'No tool' removable gear/lens tray. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. Gimbal mounted, 0-30° tiltable, external adjustable when installed. PCA version available on request.
The optional installation blockout is recommended for mounting. To be ordered separately.
The luminaire is not suitable for permanent underwater operation and must be switched off in the event of flooding.
Optional with Anti-Slip ceramic Coating ASC to DIN 51130 (Trip Classification 10) available on request.
