DAS120-PM LED PENDANT MOUNT
IP66, Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable entries. Ceiling mount through canopy. Cable suspension 1.5 - 5 ft., to be specified at time at ordering. Integral driver, thermally separated. CAD-optimized optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 0-10V Dimming comes standard with luminaire. The luminaire is factory-sealed and does not need to be opened during installation. Optional 2200 K version available, to be specified at time of ordering. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX – 9004 (Black) + XXX-XXXX (Accessory 1)
Colors
Material
| Body | Marine-grade, all aluminium construction |
| Lens | Safety glass lens |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone CCG® Controlled Compression Gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Corrosion Protection | 5CE |
| Mounting | Ceiling mount through canopy, drop guard through wire rope. Factory sealed till canopy. Cable suspension 0.5 m, ceiling mount through canopy. Longer cable suspension available on request |
Electrical
| Ballast / Driver | Integral EC electronic converter in thermally-separated compartment |
| Cable | Two cable entries on canopy for trough wiring |
| Power Supply | 220-240V / 50-60 Hz |
| Surge Protection | 1/2 kV (optional SP10) |
