AM series
AML-V Type 2
Round tapedred curved aluminum pole with double horizontal luminaire mounting arm. Chromated pre-treatment with superiror powdercoat finish in black RAL 9004, grey metallic RAL 9007, white RAL 9016 or dark bronze RAL 8019. Specify finish. Consult WE-EF color chart for other options. Service door with tamper-proof hardware. Base plate welded to tubular shaft. Aluminum base plate cover. 2 or 3 sections depending on pole height.
Twin luminaire mounting arrangement. Specify suitable horizontal tenon for intended luminaire at top section, and the mid section.
| Part-ID | D2 | D×L1 | H1 | H2 | Wall Thickness | Weight |
|---|---|---|---|---|---|---|
| 693-3625 | 7 | ø 2.38 x 3.94/ ø 1.66 x 3.94 | 25 ft | 9 ft 8 in | 0.19 | 105 |
| 693-3628 | 7 | ø 2.38 x 3.94/ ø 1.66 x 3.94 | 28 ft | 13 ft 6 in | 0.19 | 120 |
