AM series
AMW-Z-MA
Impregnated Mahogany (MA) straight round pole. Base section made of tubular steel, hot dipped galvanized inside and outside. Chromated with superior powdercoat finish in black RAL 9004, grey metallic RAL 9007, white RAL 9016 or dark bronze 8019. Specify finish. Consult WE-EF color chart for other options. Service door with stainless steel locking hardware. Base plate welded to tubular shaft.
Please specify RAL colour reference number according to the WE-EF RAL Colour Chart.
Wood is a natural material and therefore susceptible to higher colour and texture variations. Natural ageing is part of the product. We recommend to use a suitable wood stain every 12 months for maintenance and protection.
Special version with surface mounting flange plate on request.

| Part-ID | D1 | D2 | H1 | H2 | Spigot | T1 | Weight |
|---|---|---|---|---|---|---|---|
| 693-9308 | 6 | 6 | 8 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 132 |
| 693-9310 | 6 | 6 | 10 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 151 |
| 693-9312 | 6 | 6 | 12 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 184 |
| 693-9314 | 6 | 6 | 14 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 203 |
| 693-9316 | 6 | 6 | 16 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 220 |
| 693-9318 | 6 | 6 | 18 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 246 |
| 693-9320 | 6 | 6 | 20 ft | 15.75 in | Ø 3. x 5.12 | 3.5 x 15.75 | 266 |
