IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Separate LED driver. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

RAL8019 Dark Bronze

Material

Body	Marine-grade, all-aluminium construction
Fasteners	PCS Polymer Coated Stainless Steel hardware
Gasket	Silicone rubber gasket
Impact Protection	IK09
Ingress Protection	IP67
Finish	Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Corrosion Protection	5CE Corrosion protection system

Electrical

Ballast / Driver	Separate LED driver with 0-10V Interface
Cable	4 ft connecting cable
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.

Additional Information

Lifetime

Ta=25°/40° L90B10 > 90000h

Light Distribution

Rated Lumen

Color Temperature

Part-ID	Light Distribution	Light Source	Rated Lumen	CRI	Specifications		Photometrics
					Text	PDF
187-0001	symmetric linear, medium beam [LM]	LED-16/10W / 225 mA - 3000 K	1070.2	80			ULD
187-0005	symmetric linear, narrow beam [LN]	LED-16/10W / 225 mA - 3000 K	1050.6	80			ULD
187-0009	symmetric linear, very narrow beam [LVN]	LED-16/10W / 225 mA - 3000 K	1203	80			ULD
187-0023	symmetric linear, wide beam [LW]	LED-16/10W / 225 mA - 3000 K	957.9	80			ULD
187-0031	symmetric linear, medium beam [LM]	LED-16/10W / 225 mA - 4000 K	1070.2	80			ULD
187-0032	symmetric linear, narrow beam [LN]	LED-16/10W / 225 mA - 4000 K	1050.6	80			ULD
187-0033	symmetric linear, very narrow beam [LVN]	LED-16/10W / 225 mA - 4000 K	1203	80			ULD
187-0034	symmetric linear, wide beam [LW]	LED-16/10W / 225 mA - 4000 K	957.9	80			ULD
187-0531	symmetric linear, wide beam [LW]	LED-16/10W / 225 mA - 2700 K	957.9	80			ULD
187-0459	symmetric linear, medium beam [LM]	LED-16/10W / 225 mA - 2700 K	1024.9	80			ULD
187-0532	symmetric linear, narrow beam [LN]	LED-16/10W / 225 mA - 2700 K	1050.6	80			ULD
187-0533	symmetric linear, very narrow beam [LVN]	LED-16/10W / 225 mA - 2700 K	1203	80			ULD
187-0576	symmetric linear, wide beam [LW/IW]	LED-16/10W / 225 mA - 2700 K	425.8	80			ULD
187-0476	symmetric linear, wide beam [LW/IW]	LED-16/10W / 225 mA - 3000 K	425.8	80			ULD
187-0477	symmetric linear, wide beam [LW/IW]	LED-16/10W / 225 mA - 4000 K	425.8	80			ULD
187-0577	symmetric linear, medium beam [LM/IW]	LED-16/10W / 225 mA - 2700 K	534.4	80			ULD
187-0478	symmetric linear, medium beam [LM/IW]	LED-16/10W / 225 mA - 3000 K	534.4	80			ULD
187-0479	symmetric linear, medium beam [LM/IW]	LED-16/10W / 225 mA - 4000 K	534.4	80			ULD
187-0578	symmetric linear, narrow beam [LN/IW]	LED-16/10W / 225 mA - 2700 K	556.8	80			ULD
187-0480	symmetric linear, narrow beam [LN/IW]	LED-16/10W / 225 mA - 3000 K	556.8	80			ULD
187-0481	symmetric linear, narrow beam [LN/IW]	LED-16/10W / 225 mA - 4000 K	556.8	80			ULD

Showing 1 to 21 of 21 entries.
